Product Details:
|
Arm Type High Voltage Approach Electric Alarm provide a safe, practical and convenient new type high voltage alarm device for close-electric operator. During live electric working, the safe distance between operator and live body should not be closer than the requirement of relevant working regulations. After the operator wearing this alarm, when close to the high voltage charged body for a certain distance, according to the corresponding safe distance of voltage level, the alarm will make out the sound and light alarm to remind the electrical workers to pay attention to safety and avoid high voltage electric shock accidents.
| Product Name | Voltage Alarm Range | Application |
| Arm Type HV Approach Electric Alarm | 1kV～500kV | High voltage alarm |
Alarm Voltage And Distance
| Voltage Level | Working Distance |
| 6.6kV | 0.6m |
| 10kV | 0.8m |
| 35kV | 1.4m |
| 66kV | 1.8m |
| 110kV | 2.2m |
| 220KV | 3.0m |
| 330KV | 3.6m |
| 500KV | 4.2m |
Technology Parameter
| Function | Approach Electric Alarm |
| Power Supply | CR1632(140mAH)button cell 2PCS |
| Alarm Voltage Range | 1kV～500kV(high voltage alarm) |
| Alarm Distance Error | ±10cm(23℃±1℃,80%Rh,under base condition) |
| Working Frequency | 50Hz/60Hz |
| Electricity Testing Mode | Non-contact mode |
| Detection Mode | Automatic trigger |
| Battery Life | Continues working(sound and light alarm):about 24 hours |
| Standby time:about 12 months | |
| Alarm Mode | Indicator: LED light visiblity under 8000LX visible light |
| Buzzer:above 60dB(60CM apart) | |
| Weight | 351g(include battery) |
| Dimensions | 88mmX32mmX30mm |
| Protection Level | IP54 |
| Working Temperature | -10℃～40℃；below 80%rh |
| Store Temperature |
-10℃～60℃；below 70%rh
|
